Solar-powered power generation system for generating 24V DC and 230V AC voltage.
Areas of application: Small weekend house, allotment garden, alpine hut, animal stable, allotment garden, vineyard,
mountain hut and everywhere where no electricity is available.
In order to provide electrical energy even at night or when the sky is overcast, the system is equipped with rechargeable batteries.
The sine wave inverter produces a very clean and interference-free alternating voltage,
also ideal for computers, TVs and other sensitive electronic devices.
This stand-alone system can be subsidised by public funds !


Energy storage:
Solar battery AGM longlife.
Capacity: 2,4 KWH
Voltage: 24V
Operating time with fully charged battery 4 hours at 400 W continuous consumption
(or 24 hours at 60 W continuous consumption / 20W continuous consumption).
The higher the consumption, the shorter the operating time will be.
Please note that pumps and motors require about twice as much power when switched on.

Inverter:
Combination power supply for photovoltaic, mains and battery operation.
Battery charging can be done from the solar panels or from the mains.

Inverter output:
Output voltage: 230V
Single-phase
Waveform: Pure sine, interference-free
Frequency: 50 -60Hz, auto-sensing
Continuous load: 1000 W
Short-term peak load (starting current for motors): 2000 W
Selectable priority for solar battery or mains operation.
Automatic switchover if the selected energy source no longer supplies sufficient power (e.g. mains power failure, battery empty)
Switching time: typ. 10 ms
Efficiency: 98
Short-circuit protection and overload circuit.

Solar input:
PWM low-loss controller.
Max. Charging current: 30A
Solar module power: Max. 800W
Solar voltage: 30 - 60V DC

Mains input:
Voltage: 90-280V 50 - 60 Hz

For battery voltage: 24V with terminals (e.g. car batteries)
Max. Battery charging current for mains charging: 20/30A

Standby power consumption only 2W
Temperature range: 0 - 55°C
Housing: aluminium
Dimensions: H 355mm, W 272mm, D 100mm
The inverter must be placed in a house or hut.

Solar modules:
Monocrystalline
Power: 650Wp
Efficiency: 19%
sealed and hailproof,
Life expectancy approx. 25 years
The high-quality solar cell technology also guarantees charging on cloudy days.
Dimensions: 2 pieces, each 1650 x 1006 x 38mm without guarantee, with stable aluminium frame.

The system is delivered ready for connection and consists of the following components:
2 solar modules,
1 inverter
2 solar batteries
2 mounting brackets for solar module for mounting on a flat roof or slightly sloping roof. (other installation options on request)
1 solar charge controller
6 metres of cable to the solar modules.
Battery cable
Installation instructions

Inverter and batteries must be placed in a dry place or in a weatherproof housing, but not in living rooms.
(Weatherproof housing can be ordered separately)
